NOVA KOOL RFU8220DC 206 Litre Fridge/Freezer Made in Canada
206 Litres Total Internal Volume:
161 litres of fridge space at the top where everyday items are easy to reach.
The 45 litre freezer space is on the bottom.
1342 mm (H) X 590 mm (W) x 546 mm (D)
The RFU8220 is equipped with a highly efficient variable speed Danfoss BD35F compressor (fan included) that is designed for use in boats, caravans and RV's running 12 and 24 volts DC.
Power draw is ~ 5.0 amps when running on 12 volts: average power use will vary depending on ambient temp. how often the door is opened etc.
DC only: 12 & 24vdc standard, optional 10-45vdc for special applications (please contact us!)
AC/DC: 12 & 24vac and 100-240vac 50/60HZ
RFU8220 DC - Upright Fridge Freezer
Configuration = 2 Door Upright - freezer on the bottom.
Gross Shippng Weight: 45 kg's
Voltage: 12 or 24 Volts DC (Optional AC/DC available)
Compressor: Danfoss / SECOP BD35F
Control Module: Danfoss 101N0210
Total volume: 206 litres ( 8.2 cu.ft. )
Fridge space: 161 litres
Freezer space: 45 litres
Cut Out Dimensions
1342 mm Height
590 mm Width
495 mm Depth at the top (measured from the back face of the mounting flange at the top)
298 mm Depth at the bottom (measured from the back face of the mounting flange at a point 190mm from the bottom)
Overall dimensions (Including flange)
1355mm Height
629 mm Width
505 mm Depth at top (including door and latch handle)
308 mm Depth at bottom
Standard Options
- Multi-Voltage module for AC/DC operation switches automatically between AC and DC power sources: 12 or 24 VDC and 100-240 VAC 50/60Hz
- White or Stainless Steel door panels (black panels are standard)
- Right or left hand door swing (right is standard)
Note on door swing:
If you require a left hand door swing (hinge on the left) please specify this requirement when ordering and we will change this for you: there is no charge for this service.
