Model: CMS-ADAPT-02

This adaptor converts C Series CMS connections to Jayco Type CMS power points for 230Vac systems in recreational vehicles.

Features

• Plug and Play Installation: Simple DIY fitting for AC power points and cables in caravans, motorhomes, and RVs.
• Compatibility: Connects C Series CMS power inlets to Jayco J Series outlets.
• Australian & NZ Standard Compliance: Meets AS/NZS 3112, AS/NZS 61535.1, and AS/NZS 3000 electrical safety standards.
• Circuit Requirements: Works with 16A circuit breakers or RCDs to protect each electrical circuit.
• Design: Cables have sealed ends; ensure extra length for installation and future replacement.
• Power Point Recess: Requires 32mm recess depth; mounting blocks available for surface fitting if needed.
• Modular Wiring: Supports daisy-chaining power points with male/female connectors and security clips.
• Versatile Use: Ideal for adding external outlets or branching circuits within RV electrical systems.

Installation Overview

Use the CMS power inlet to connect 230V, 15A power via an extension lead. Plug the 16A circuit breaker loom into the inlet, then connect to the first power point. Additional points connect sequentially using loom connectors. The final power point uses the inlet only, leaving the outlet free for future use or external outlets, such as under awnings. Double pole switches are included as required for recreational vehicle safety.

Adapters and junction connections allow branching off from main lines to create separate circuits for devices like battery chargers, air conditioning, or hot water systems.

Installation Tips

• Each cable end measures approx. 25mm x 16mm and must fit through framing if installed post-sheeting.
• Use the security clip to lock cable connections securely; manual release needed to disconnect.
• Allow extra cable length when wiring inside walls to facilitate future power point replacements.

CMS Electracom products reduce electrician time by enabling builders to pre-wire 230V components during vehicle construction, limiting electrical work on-site to final testing and certification.
