Drawer Slide and High Side Kit - DS560-1000mm

Wide Tunnel Boot Drawer and Storage Tub Kit for Caravan and RV Setups

The DS560-1000mm Drawer Slide and High Side Kit from On The Go RV Accessories is the ideal solution for transforming your tunnel boot into a functional, enclosed storage space. Proudly Australian made from premium 3mm aluminium with a satin black powder-coated finish, this kit combines a heavy-duty slide with custom-fit high sides. With a 125kg load rating and lockable slide tracks, you get secure, smooth operation and added protection for your gear.

Features

• Australian made using 3mm mill finish aluminium for superior strength
• Satin black powder-coated finish for corrosion resistance and a clean look
• 125kg load rating with LOCK IN/LOCK OUT functionality for safety and convenience
• Internal tray size: 1015mm (L) x 495mm (W)
• Closed length: 1050mm (including front tabs) | Open length: 1990mm
• Overall width: 565mm (includes dome nuts) | Height: 80mm
• Weight: 14kg
• Lockable drawer tracks keep contents secure during travel
• Kit includes DS560 drawer slide, HS560 high side set, and 316 stainless steel fixings
• High sides made from 2mm aluminium and come flat packed with 4 sides and 16 bolts
• Product code: DS560-1000KIT

Uses and Applications

• Perfect for converting tunnel boot space into a secure storage tub
• Ideal for holding tools, BBQs, hoses, recovery gear, and outdoor equipment
• Great for caravans, camper trailers, and motorhomes needing wide-format storage
