Autoterm 2D Diesel heater install

Tank install behind the stone guard

Tank from the other side

Heater mounted under the seat

With the Autoterm we can set the temperature measuring point to inside the heater. This means we can properly regulate the temperature and output of the heater.

Fusing is supplied on the Autoterm loom.


Exhaust sloping down and doubling back so not in the direction of travel

Air intake towards the centre of the camper. Lowest point of the air intake we drill a hole to allow water and dust to escape.

Fuel pump tucked up out of the way. All cables conduit-ed and out of harms way.
